Модуль конвертер I2S в аналоговое аудио на CS4344
Introduction:
This is a test design board for the CS4344 lc. The CS4344 is a complete stand-up digital-to-analog conversion output system that includes interpolation in a 10-pin package, multi-bit D/A conversion and output analog filtering. The CS4344 has a 12S interface.
Note: You need 12S with MCLK signal
Instructions for use:
- SDIN: Serial audio data input
- SCLK: External serial clock input
- LRCK: left and right clock input, determine which channel left or right is currently active on the serial audio data line
- MCLK: master clock, clock source for modulator and digital filter
- GND: Ground
- VCC: power terminal
